The BBF-HDMI-LED microscope package is offered in collaboration with Dr. Jerome Rerucha from the Brain/Body Fit® podcast. It provides upgraded infinity optics and specialised objectives to further increase clarity and convenience in a busy live & dry blood analysis practice.

Learn more about Dr. Jerome Rerucha and the Brain/Body Fit® podcast here: https://www.performancepractic.com/brain-body-fit-podcast

• Illumination: 9W LED illumination, adjustable (equivalent to 100W halogen).
• Camera: Full-HD HDMI-USB Digital C-mount Camera (1920 x 1080) with dual video output via USB and HDMI ports.
• Microscope Body: Hard-wearing solid metal structure, more durable than many other brands.
• Magnification Range: Eyepieces: 12,5X – 1000X / On-Screen: 50X – 4000X.
• Eyepieces: Wide-Field 10X (20X optional).
• Stage: Ergonomic mechanical stage with low position co-axial controls.
• Movement Range: 76 x 50 mm. Size: 160 x 140 mm.
• Focusing System: Co-axial coarse and fine focus, with adjustable tension and stopper.
• Field Diaphragm Diameter: 2-35mm.
• Microscope Head: Siedentof Trinocular Head with built-in infinity-corrected optical magnification system (40X).
• Optical System: Infinity-corrected
• Condensers: Interchangeable brightfield and darkfield condensers.
  • Brightfield condenser: Abbe condenser with frosted filter NA=1.25.
  • Darkfield condenser: Oil immersion cardioid darkfield condenser.
• Objectives: Infinity-corrected objectives

• Apochromatic 1.25X
• Plan-achromatic: 10X
• Plan-achromatic:  25X
• U-Plan-achromatic: 40X spring
• Plan-achromatic: 100X spring (oil w/ iris)

SPECIFICATIONS STANDARD ON ALL MODELS:

Please Note: Laptop and monitor not included.
